Detonation Database

Cell width vs. percent diluent; CH4-N2O-Diluent

Postscript Version

ja7a.txt Akbar (1997) [3] T=293 K, P=57-72 kPa, ER=1, 0-50% N2

ja7b.txt Akbar (1997) [3] T=293 K, P=77-87 kPa, ER=1, 37.5-50% N2

ja7c.txt Akbar (1997) [3] T=293 K, P=92-97 kPa, ER=1, 54.5-58.3% N2

ja7d.txt Akbar (1997) [3] T=293 K, P=102 kPa, ER=1, 61.5-64.3% N2

ja7e.txt Akbar (1997) [3] T=293 K, P=86-97 kPa, ER=0.5-0.7, 48.8-65.1% Air
